[pianotech] S&S K(52) Restoration

[Delwin D Fandrich]

Yes, it is. That is part of the Z-Bar and "floating bass" design.



ddf



Delwin D Fandrich

Piano Design & Fabrication

6939 Foothill Court SW, Olympia, Washington 98512 USA

Phone  360.515.0119 - Cell  360.388.6525

 <mailto:del at fandrichpiano.com> del at fandrichpiano.com -
<mailto:ddfandrich at gmail.com> ddfandrich at gmail.com



From: pianotech-bounces at ptg.org [mailto:pianotech-bounces at ptg.org] On Behalf
Of Gene Nelson
Sent: Thursday, May 17, 2012 6:58 PM
To: pianotech at ptg.org
Subject: Re: [pianotech] S&S K(52) Restoration



Extraordinarily steep grain angle.

Do you have a pic of the other side?

Gene



  _____

From: pianotech-bounces at ptg.org [mailto:pianotech-bounces at ptg.org] On Behalf
Of Terry Farrell
Sent: Thursday, May 17, 2012 6:51 PM
To: pianotech at ptg.org
Subject: Re: [pianotech] S&S K(52) Restoration



Gene - IMHO, you really need to have a lengthy conversation with Del. His
design modifications produced an incredible sound from my M&H upright.....







Terry Farrell



PS: Oh, and after you glue in that new soundboard (hide glue, preferably)
and need to clean up any squeeze-out, I've got just the solution for
you......  ;-)









On May 17, 2012, at 8:48 PM, Gene Nelson wrote:



Just getting it apart now so I can measure and record the scale.
No wound trichords to deal with but no trans bridge. - not ruling out one
for redesign depending on the scale. The end of the tenor bridge come very
close to the bottom board/rim structure. The bass bridge seems more nicely
positioned.
Bass bridge is canto levered and straight. The canto lever will go.
Huge birdseye maple space filler/cut off device in the lower right and a
smaller cut off bar in the upper left. Might just keep that part the way it
is.
Do you know if those pins that look like bridge pins - driven into the plate
- that offset/terminate the wound bass strings just below the tuning pins
are removable?
Gene
