John,

            Seems like you have at least one good leg on each of the pulleys from which to determine radius. Radius times 2 plus hub plus outer thickness of pulley, no?





Greg Newell

Greg's Piano Forte

216-226-3791 (office)

216-470-8634 (mobile)

www.gregspianoforte.com

gpf at ameritech.net







From: pianotech-bounces at ptg.org [mailto:pianotech-bounces at ptg.org] On Behalf Of John Ross
Sent: Friday, March 01, 2013 9:15 PM
To: Pianotech List
Subject: [pianotech] Photo Duo-Art Steamboat Pump






I am looking for the pulley sizes for this pump.
One is distorted and the other has disintegrated.







It was suggested to me to do away with the double and quadruple pulleys and use a 1/2” V belt.
I don’t want to change the ratios so I am hoping someone can give me the dimensions that the replacement pulleys should be.
Thank you.
John Ross
Windsor, Nova Scotia
